Large Diameter Bundled Conductor Stringing Block Pulley For Cable Pulling and Stringing

Name: Large Diameter Bundled Conductor Stringing Block Pulley For Cable Pulling and Stringing
Brand: XINYA
Price: 1 USD

China Large Diameter Bundled Conductor Stringing Block Pulley For Cable Pulling and Stringing wholesale

Brand Name : XINYA

Model Number : FH

Certification : ISO

Place of Origin : Jiangsu,China

MOQ : 1set

Price : get latest price

Payment Terms : L/C, T/T,

Packaging Details : 1000 sets per month

Application : Overhead Transmission Line

frame : steel

size : 508/660/916mm

Usage : stringing

Type : Block And Tackle

Material : Nylon or Aluminum sheave

Contact Now

Large Diameter Bundled Conductor Stringing Block Pulley For Cable Pulling and Stringing

Uses: Apply to paying off single conductor, twin bundled conductor or four bundled conductor on overhead transmission line construction.
Specification: Product can be made of aluminum wheel with rubber liner, MC nylon wheel with rubber liner or strengther nylon wheel with PU liner.

Item No.	Model No.	Sheave Number	Rate Load (KN)	Unit Weight (KG)	Sheave Features
0357	SHD508	Single	20	18	Aluminum wheel with rubber liner
0358	SHDN508	Single	20	16	MC nylon wheel
0359	SHSLN508	Three	40	47	Middle: MC nylon wheel Condctor: Aluminum wheel with rubber liner
0360	SHWLN508	Five	60	79
0361	SHSQN508	Three	40	43	MC nylon wheel
0362	SHWQN508	Five	60	70	MC nylon wheel

Note:

1. Max applicable conductor is ACSR400.
2. Sheave diameter(external diamter x groove diameter x width) is Ф508 x Ф408 x 75 mm.

Item No.	Model No.	Sheave Number	Rate Load (KN)	Unit Weight (KG)	Sheave Features
0363	SHD660	Single	20	30	Aluminum wheel with rubber liner
0364	SHDN660	Single	20	24	MC nylon wheel
0365	SHSLN660	Three	40	92	Middle:MC nylon wheel Conductor: Aluminum wheel with rubber liner
0366	SHWLN660	Five	60	120
0367	SHSQN660	Three	40	76	MC nylon wheel
0368	SHWQN660	Five	60	110	MC nylon wheel

Note:

1.Max applicable conductor is ACSR500.
2.Sheave diameter(external diamter x groove diameter x width) is Ф660 x Ф560 x 100 mm.

Item No.	Model No.	Sheave Number	Rate Load (KN)	Unit Weight (KG)	Sheave Features
0369	SHDN822	Single	30	25	MC nylon wheel
0370	SHSQN822	Three	60	118
0371	SHWQN822	Five	120	180

Note:

1.Max applicable conductor is ACSR630.
2.Sheave diameter(external diamter x groove diameter x width) is Ф822x Ф710 x 110 mm.

Large Diameter Bundled Conductor Stringing Block Pulley For Cable Pulling and Stringing

Packing & Delivery

Packing Details : Usually, the products should be bulk pack into wooden board carton.
Delivery Details : We always making stock of regular items in order to satisfy market demand so the delivery time is very
quick.
